ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default

ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default
ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default
ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default

Ampliación de imagen :  ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default

Datos del producto:
Lugar de origen: EE.UU
Nombre de la marca: Cisco
Certificación: CE
Número de modelo: ISR4221-SEC/K9
Pago y Envío Términos:
Cantidad de orden mínima: 1
Precio: $625-$2043
Tiempo de entrega: 1 a 2 días
Condiciones de pago: L/C, D/A, D/P, T/T, Western Union, Moneygram
Capacidad de la fuente: 500 por semana
Contacto

ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default

descripción
Condición: Nuevo Garantía: 1 año
Tiempo de entrega: 1-2 días Las dimensiones (H x W x D): 1,72 x 12,7 x 10 en (43,7 x 322,6 x 254 milímetros)
Tipo: Enrutador Slot de ISC a bordo: 1
Marca: Cisco Modelo: ISR4221-SEC/K9

ISR4221-SEC/K9 Overview

Quick Specs

Table 1 shows the Quick Specs.

Product Code Cisco ISR4221-SEC/K9
Bundle Cisco ISR 4221 SEC Bundle with SEC lic
Aggregate Throughput 35 Mbps to 75 Mbps
Total onboard WAN or LAN 10/100/1000 ports 2
RJ-45-based ports 2
SFP-based ports 1
NIM (Network Interface Modules) slots 2
Onboard ISC slot No

Default memory double-data-rate 3 (DDR3) error-correction-code

(ECC) DRAM (Combined control/services/data planes)

 4 GB
Flash Memory 8 GB
Power-supply options External AC only
Rack height 1 RU
Dimensions (H x W x D) 1.72 x 12.7 x 10 in (43.7 x 322.6 x 254 mm)
Weight with AC PS (no modules) 7.1 lb (3.22 kg)

Product Details

Figure 1 shows the LEDs on the front panel of the Cisco ISR4221-SEC/K9.

ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default 0

·There are 4 LEDs on the front panel.

Figure 2 shows the back panel of Cisco ISR4221-SEC/K9.

ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default 1

Note:

① GE 0/0/0 RJ-45 (copper cable) port ⑤ Console port
② Power switch ⑥ GE 0/0/1 (copper cable) port
③ Power input connector ⑦ GE 0/0/0 SFP (fiber-optic) port
④ GE “MGMT” port (with USB port below) ⑧ NIM slots

Figure 3 shows the Security License function.



ISR4221-SEC/K9 ISR 4321 with 2 onboard GE, 2 NIM slots, 1 ISC slot, 4 GB Flash Memory default, 4 GB DRAM default 2

The Modules & Cards

Table 2 shows some recommended modules and cards.

Items Models Description
Console and Auxillary Cables CAB-CONSOLE-RJ45 Cisco CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F
Network Interface Modules NIM-1MFT-T1/E1 Cisco Fourth-Generation Multiflex Trunk Voice and WAN network interface module
NIM-ES2-4 Cisco 4000 Series Integrated Services Router 4-Port Gigabit Ethernet Switch Module layer 2
NIM-ES2-8 Cisco 4000 Series Integrated Services Router 8-Port Gigabit Ethernet Switch Module NIM
SFPs for On-Board GE Ports GLC-LH-SMD Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM
GLC-ZX-SMD Cisco GLC-ZX-SMD 1000BASE-ZX SFP transceiver module, SMF, 1550nm, DOM
GLC-SX-M MD Cisco GLC-SX-M MD 1000BASE-SX SFP transceiver module, MMF, 850nm, DOM

Compare to Similar Items

Table 3 shows the comparison.

Models ISR4221/K9 ISR4221-SEC/K9
Bundle N/A Cisco ISR 4221 SEC Bundle with SEC lic
Aggregate Throughput 35 Mbps to 75 Mbps 35 Mbps to 75 Mbps

Total onboard WAN or

LAN 10/100/1000 ports

 2 2
RJ-45-based ports 2 2
SFP-based ports 1 1
NIM slots 2 2
Rack height 1 1

ISR4221-SEC/K9 Specification

Model
ISR4221-SEC/K9
Brand
Cisco
Bundle
Cisco ISR 4221 SEC Bundle with SEC lic
Aggregate Throughput
35 Mbps to 75 Mbps
Total Onboard WAN or LAN 10/100/1000 Ports
2
RJ-45-based Ports
2
SFP-based Ports
1
Enhanced Service-Module Slots
0
Doublewide Service-Module Slots
0
NIM Slots
2
OIR (All I/O Modules)
No
Onboard ISC Slot
No
Default Memory DDR3 ECC DRAM (Combined Control/Services/Data Planes)
4 GB
Maximum Memory DDR3 ECC DRAM (Combined Control/Services/Data Planes)
4 GB
Default Flash Memory
8 GB
Maximum Flash Memory
8 GB
External USB 2.0 Slots (Type A)
1
USB Console Port Type B Mini (Up to 115.2 kbps)
0
Serial Console Port - RJ45 (Up to 115.2 kbps)
1 (combo CON/AUX port)
Serial Auxiliary Port - RJ45 (Up to 115.2 kbps)
1 (combo CON/AUX port)
Power-Supply Options
External: AC Only
Redundant Power Supply
N/A
AC Input Voltage
100 to 240 VAC autoranging
AC Input Frequency
47 to 63 Hz
AC Input Current Range, AC Power Supply (Maximum)
1.5 to 0.6A
AC Input Surge Current
90 A peak and less than 3 Arms per half cycle
Typical Power (No Modules) (Watts)
24
Maximum Power with AC Power Supply (Watts)
90
Maximum Power with PoE Power Supply (Platform Only) (Watts)
NA (No PoE Support)
Maximum Endpoint PoE Power Available from PoE Power Supply (Watts)
NA (No PoE Support)
